High-Speed U Channel Metal Stud and Track Roll Forming Machine

文章目录

• Core feature:
• Application scenario:
• Pattern diagram：
• Product Attributes :
• Machine image:
• Contact Us：

High-Speed U Channel Metal Stud and Track Roll Forming Machine is not a simple roller press, but a highly integrated automated molding production line. It is mainly composed of the following units connected in series:

1.Hydraulic unwinding machine
2.Servo feeding and hydraulic punching system
3.Multi pass cold bending forming host
4.Hydraulic follow-up cutting system:
5.Automatic material receiving platform

Core feature:

1. One machine dual-use, U-rail and C-screw can be switched freely
2. Online punching, cutting and installation
3. High speed and precision, ultra-low material loss
4. Intelligent control, one person managing the front line
5. Cold bending strengthening, lighter and stronger

Application scenario:

• Non load bearing indoor partition walls:
  office buildings, shopping malls, hotel rooms, and residential partition walls require a large number of U-shaped and C-shaped vertical keels of different lengths, and flexible production perfectly matches diverse needs.
• Suspended ceiling system:
  Various main and auxiliary keels and corners of the suspended ceiling, with complex cross-sections, can be flexibly handled by the molding machine to ensure flatness and installation accuracy.
• Light steel villas and modular houses:
  wall frame, floor beam, roof beam, cold-formed light steel keel is the main load-bearing or enclosure structural component, with extremely high requirements for strength, accuracy, and batch punching. The advantage of online integrated molding is obvious.

Pattern diagram：

Product Attributes :

1.Formed Material	PPGI,GI,AI		Thickness:2-3mm
2.Decoiler	Hydraulic automatic decoiler		Manual decoiler(will give you as free)
3.Main body	Roller station		As your requirement
	Diameter of shaft		40mm solid shaft
	Material of rollers		45# steel, hard chrome plated on the surface
	Machine body frame		Metal steel welded
	Drive		Chains transmission
	Dimension(L*W*H)		7800*800*1200(customize)
	Weight		About 4.5T
4.Cutter	Automatic		cr12mov material, no scratches, no deformation
5.Power	Motor Power		7.5KW*2 sets
	Hydraulic system power		5.5KW
6.Voltage	380V 50Hz 3Phase		As your requirement
7.Control system	Electric Box		Customized(famous brand)
	Language		English(Support multiple languages)
	PLC		Automatic production of the whole machine. Can set batch, length, quantity, etc.
18.Forming Speed	40-100m/min(customized)		Different speed designs for options.

Machine image:

Contact Us：

Contact us immediately for customized molding solutions and investment return analysis. Let your dragon bone production line be one step ahead from now on!
