The automatic tile pressing machine mainly consists of left and right body, bottom link, top chassis cover, sliding seat, hexagonal wheel, pulley, gear mechanism, sheave mechanism, cam mechanism, lubrication pump, oil circuit system, electronic control part, etc. The upper die stamping process of the machine: the motor drives the input shaft through the pulley, drives the upper shaft through the pinion and the large gear, and drives the sliding seat with the upper mold to move up and down through a set of cam mechanism to realize the pressing tile. The indexing is carried out by the gear set mounted on the upper end of the shaft, the transmission pin gear, and the groove wheel mounted on the hexagonal wheel shaft to realize the indexing positioning, and one of the two ends of the upper shaft is mounted and mounted. The return cam conjugated to the pressing cam on the shaft, the positioning of the lower mold in the working position is realized by the positioning rod and the positioning disc. In the left and right sides of the chassis, a lubrication pump is installed, and the machine passes through the working pipe, and the oil pipe is transported to each friction moving part. Lubricating oil. The table of the automatic tile pressing machine has six processes, (ie, the hexagonal wheel).

The table is turned over. In addition to the first-level mechanical indexing and positioning, a set of precise positioning mechanism is also provided to ensure each stamping process. Workbench Accurate positioning, the sliding table for mounting the upper mold is the box structure, the slide rail and the upper rail of the fuselage, the contact length is large, each stamping of the upper mold, the process has a secondary punching of the mud blank, that is, the upper mold pressing After the blank is in place, the upper mold rises by 10mm, so that the mud blank is fully exhausted, and the upper mold is pressed down to the position, and then returns to the high position, so the mold has a long service life and the quality of the pressed product is good.
